The DUET tap series sets the new benchmark for public restroom solutions. With the first actuation of the Smart Tap, soap is released and afterwards a smooth water flow for a clean, hygiene, and efficient handwashing.

Product Specification

• Available Finishes: Chrome, Matt Black, Stainless Steel or selected PVD Coatings
• Easy installation
• Deck mounted
• Vandal-resistant
• Power Supply AC/DC
• Hidden Aerator  0.5 gpm / 1.9 lpm
• Hidden Sensor Unit
• Secure Fixing Nut with Screws
• Spout reach 124 mm

Water Parameters

• Max. continuous flow 60 sec
• Water ON  0.4 sec
• Water OFF  1.5 sec
• Sensing range 200 - 350 mm
• Water pressure 0.1 – 0.8 MPa static
• Ambient temperature 1 – 55 °Celsius

Foam Soap Parameters

• Soap discharge time 2 sec
• Soap discharge 1.5ml/sec at 1000 cps
• Optimal soap viscosity 1000 – 3500 cps
• Soap bottle 1.0 L

Product Configuration Options

• Soap Bottle with different volume
• Antibacterial Liquid Soap
• Fittings (Push Pop-Up Waste, P-Trap, Angle Valve, Connection Hose)

Compliant with

• Chrome surface: pass 24h Acid Salt Spray Test
• WRAS
• LEED
• WELS 3 Ticks PPP

Product Group Code: F207F-D
